SHARVIN.OS
Thoovanathumbikal · 1987

തൂവാനത്തുമ്പികൾ

Thoovanam

Two Malayalam display fonts — a tribute to the title lettering of Thoovanathumbikal (1987).

Thoovanam · v2.000 · 1017 glyphs · 11 traced

Type the film's title and get a poster's own letterforms; type anything else and get a face built to sit beside them. Version 1 comes from the re-release poster: cream, round and soft-cornered. Version 2 comes from the original 1987 print: red ink, heavy, letters shoulder to shoulder. Both share one body of about a thousand letters, engineered from Baloo Chettan 2, and they install side by side.

പി. പത്മരാജന്റെ തൂവാനത്തുമ്പികൾ (1987) എന്ന ചിത്രത്തിന്റെ പോസ്റ്ററുകളിലെ തലക്കെട്ടിനോടുള്ള ആദരവായി രൂപകൽപ്പന ചെയ്ത രണ്ട് മലയാളം ഡിസ്പ്ലേ ഫോണ്ടുകൾ. തൂവാനത്തുമ്പികൾ എന്ന് ടൈപ്പ് ചെയ്താൽ പോസ്റ്ററിലെ അതേ അക്ഷരങ്ങൾ കിട്ടും; മറ്റെന്തും ടൈപ്പ് ചെയ്താൽ അവയ്ക്കൊപ്പം ചേരുംവിധം രൂപപ്പെടുത്തിയ അക്ഷരങ്ങളും. സിനിമാ തലക്കെട്ടുകൾ, പോസ്റ്ററുകൾ, തംബ്നെയിലുകൾ, റീൽ ക്യാപ്ഷനുകൾ — വലിയ വലുപ്പത്തിൽ ഉപയോഗിക്കാൻ. സൗജന്യം, ഓപ്പൺ സോഴ്സ് (SIL OFL 1.1).

Type anything

TYPE TESTER
തൂവാനത്തുമ്പികൾ
112PX

Every size

  1. 128PX

    തൂവാനത്തുമ്പികൾ

  2. 96PX

    തൂവാനത്തുമ്പികൾ

  3. 72PX

    തൂവാനത്തുമ്പികൾ

  4. 48PX

    തൂവാനത്തുമ്പികൾ

  5. 32PX

    തൂവാനത്തുമ്പികൾ

The whole script

തൂവൽ വാനം നക്ഷത്രം കാറ്റ്

തുമ്പി പാമ്പ് മാനം കുളം

ത്ത മ്പ കൾ ത്തി മ്പി പിത്തം

കാനത്തിൽ വാനമ്പാടി തുള്ളി മാല

Vowels

Consonants

Consonants (2)

Vowel signs on ക

  • കാ
  • കി
  • കീ
  • കു
  • കൂ
  • കൃ
  • കെ
  • കേ
  • കൈ
  • കൊ
  • കോ
  • കൗ
  • കം
  • കഃ
  • ക്

Chillus and conjuncts

  • ൿ
  • ക്ക
  • ങ്ക
  • ങ്ങ
  • ച്ച
  • ഞ്ച
  • ഞ്ഞ
  • ട്ട
  • ണ്ട
  • ണ്ണ
  • ത്ത
  • ന്ത
  • ന്ന

Conjuncts (2)

  • പ്പ
  • മ്പ
  • മ്മ
  • യ്യ
  • ല്ല
  • വ്വ
  • ശ്ശ
  • സ്സ
  • ള്ള
  • റ്റ
  • ന്റ
  • ക്ഷ
  • ക്ത
  • സ്ത്ര
  • ന്ദ്ര
  • ദ്ധ
  • ജ്ഞ

Ra, la, ya, va forms

  • ക്ര
  • പ്ര
  • ത്ര
  • ക്ല
  • പ്ല
  • ക്യ
  • ത്യ
  • ക്വ
  • സ്വ
  • ശ്രീ
  • സ്ഥ
  • ഷ്ട
  • ശ്ച
  • ഹ്മ

Digits and Latin

  • മലയാളം
  • എന്റെ
  • മാതൃഭാഷ
  • 0123456789
  • Thoovanam
  • ABC
  • xyz
  • !?&

From the poster

Top: the title band of the original 1987 Thoovanathumbikal poster, red lettering on tan paper. Bottom: the same words typed in Thoovanam 1987.
Version 2 — the 1987 poster (top), Thoovanam 1987 as live text (bottom)
Top: the title band of the Thoovanathumbikal re-release poster, cream lettering with a dark outline. Bottom: the same words typed in Thoovanam.
Version 1 — the re-release poster (top), Thoovanam as live text (bottom)
The letter ma as Baloo drew it, then reshaped and fattened, stems more than horizontals
One base glyph through the build
  1. 01

    Trace

    potrace turns each poster's title band into outlines: eleven letters from the re-release poster and nine from the 1987 print, including the fused tta and mpa and the 1987 poster's old-script thoo and tthu.

  2. 02

    Fit

    Baloo Chettan 2 at weight 500 is narrowed to 89.5% and its stems grown more than its horizontals, measured stroke for stroke against the 1987 letters, so the thousand untraced letters can sit beside the traced ones.

  3. 03

    Build

    build.py merges the base and the outlines, adds one ligature rule for the old-script pairs, and spaces Malayalam letters from the edges that actually face each other: 14 units, the 1987 poster's own 2 px.

  4. 04

    Verify

    The build re-opens each font and refuses to ship if a counter closed up, if a traced letter is never drawn in the title, or if HarfBuzz shapes the proof text unlike the base font.

BUILD DATA
Traced letters
11 · 9
Total glyphs
1017 · 1019
Base
Baloo Chettan 2
Weight · width
wght 500 · 89.5%
Version
2.000 · 1.000

Install and use

DESKTOP
macOS
Double-click the .ttf, then Install in Font Book. Or:cp ~/Downloads/Thoovanam-Regular.ttf ~/Downloads/Thoovanam1987-Regular.ttf ~/Library/Fonts/
Windows
Right-click the .ttf, then Install (or Install for all users).
Linux
Copy it into your fonts folder and refresh the cache:mkdir -p ~/.local/share/fonts && cp ~/Downloads/Thoovanam-Regular.ttf ~/Downloads/Thoovanam1987-Regular.ttf ~/.local/share/fonts/ && fc-cache -f

Restart the app you want it in. In Photoshop, Illustrator, InDesign, Premiere and After Effects, turn on the Middle Eastern & South Asian (World-Ready) paragraph composer, or conjuncts fall apart.

WEB

Download the WOFF2 above, host it next to your CSS, and tag the text as Malayalam with lang="ml".

@font-face {
  font-family: "Thoovanam";
  src: url("Thoovanam-Regular.woff2") format("woff2");
  font-display: swap;
}

@font-face {
  font-family: "Thoovanam 1987";
  src: url("Thoovanam1987-Regular.woff2") format("woff2");
  font-display: swap;
}

h1[lang="ml"] {
  font-family: "Thoovanam", "Baloo Chettan 2", sans-serif;
  line-height: 1.4;
}

These are display faces: use them large, for titles, posters, thumbnails and reel captions.

Licence and tribute

FONTS · OFL 1.1

The fonts, traced letters included, are under the SIL Open Font License 1.1, as the Baloo Chettan 2 they are built on requires (© 2019 The Baloo 2 Project Authors). Keep OFL.txt with them when you pass them on.

SCRIPTS · MIT

The build scripts (fonts.py, build.py, trace.py, proof.py, tools/) are under the MIT License.

TRIBUTE

An artistic tribute to Thoovanathumbikal (1987), written and directed by P. Padmarajan. Letterforms are not copyright subject matter in the United States or in India, so the traced title letters ship under the OFL with everything else. A request, not a term: keep them to personal, fan and non-commercial titling. The film, its title and its artwork belong to their rights holders; this project is not affiliated with or endorsed by them.

The two poster comparisons reproduce each poster's title band only, at proof resolution, to compare and comment on the letterforms: fair use (17 U.S.C. § 107) and fair dealing for criticism or review (Copyright Act, 1957 § 52(1)(a)(ii)). They are not licensed for any other use. Details: LICENSE.md and proofs/README.md. Nothing here is legal advice.
